Basic Information | |||
Usage | Semi-Trailer | ||
Length | 9500,9000,8500mm | ||
Width | 2550mm | ||
Height | 3950,3750,3550mm | ||
Curb Weight | 9100kg | ||
Gross Weight | 40000kg | ||
Chassis | |||
Front/Rear Overhang | -/1380,-/1080mm | ||
Number of Leaf Springs | -/4/4/4,-/8/8/8,-/10/10/10 | ||
Number of Axles | 3 | ||
Wheelbase | 4500+1310+1310,4300+1310+1310,4100+1310+1310mm | ||
Axle Load | -/24000(three axles)kg | ||
Front Wheel Track | -mm | ||
Rear Wheel Track | 1840/1840/1840mm | ||
Approaching/Departuring Angle | -/24° | ||
Tire | |||
Number of Tires | 12 | ||
Tire | 12R22.5 12PR,11R22.5 12PR,11.00R20 12PR |
