| Basic Information | |||
| Usage | Aluminum Alloy Oil Tanker | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005, GB17691-2005 national Ⅳ emission standards | ||
| Length | 11740mm | ||
| Width | 2495mm | ||
| Height | 3035mm | ||
| Curb Weight | 12870kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 102km/h | ||
| Chassis | |||
| Chassis Model | CA1310P63K2L6T4A1E4 | ||
| Front/Rear Overhang | 1400/2490mm | ||
| Number of Leaf Springs | 3/3/11,3/3/4,3/3/-,10/10/11 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+4550+1350,1950+3550+1350mm | ||
| Axle Load | 6550/6450/18000(two axles)kg | ||
| Front Wheel Track | 1950/1950mm | ||
| Rear Wheel Track | 1847/1847mm | ||
| Approaching/Departuring Angle | 20/10° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00R20 16PR,11.00-20 16PR,10.00R20 16PR,10.00-20 16PR,11R22.5 16PR,295/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CA6DL1-26E4 | China FAW Group Co., Ltd. | ||
| CA6DL1-28E4 | China FAW Group Co., Ltd. | ||
| BF6M1013-26E4 | China FAW Group Co., Ltd. | ||
| BF6M1013-28E4 | China FAW Group Co., Ltd. | ||
| BF6M1013-30E4 | China FAW Group Co., Ltd. | ||
| CA6DK1-26E4 | China FAW Group Co., Ltd. | ||
| CA6DK1-28E4 | China FAW Group Co., Ltd. | ||
| CA6DK1-30E4 | China FAW Group Co., Ltd. | ||
