| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 6990mm | ||
| Width | 2200mm | ||
| Height | 2800mm | ||
| Curb Weight | 5600kg | ||
| Gross Weight | 12495kg | ||
| Seats | 3 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | EQ1127SJ8GDC | ||
| Front/Rear Overhang | 1130/2060mm | ||
| Number of Leaf Springs | 8/10+7,8/10+7,8/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 3300,3650,3800mm | ||
| Axle Load | 4480/8015kg | ||
| Front Wheel Track | 1740mm | ||
| Rear Wheel Track | 1640mm | ||
| Approaching/Departuring Angle | 20/14° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25R20 14PR,8.25-20 16PR,8.25R20 14PR,8.25-20 16PR,9R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC4S150-50 | Guangxi Yuchai Machinery Co., Ltd. | 110kW | 3767ml |
| YC4FA130-50 | Guangxi Yuchai Machinery Co., Ltd. | 95kW | 2982ml |
| CY4BK151 | Dongfeng Chaoyang Diesel Co., Ltd. | 105kW | 3856ml |
| YCD4P4S-160 | Guangxi Yuchai Machinery Co., Ltd. | 118kW | 4580ml |
| YCD4T4S-130 | Guangxi Yuchai Machinery Co., Ltd. | 95kW | 3857ml |
