| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5998mm | ||
| Width | 2000mm | ||
| Height | 2700mm | ||
| Curb Weight | 3550kg | ||
| Gross Weight | 7360kg | ||
| Seats | 3 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | HFC1071P92K5C2ZV | ||
| Front/Rear Overhang | 1085/1605mm | ||
| Number of Leaf Springs | 4/9+7,3/9+7,5/9+7 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3308mm | ||
| Axle Load | 2640/4720kg | ||
| Front Wheel Track | 1620mm | ||
| Rear Wheel Track | 1395mm | ||
| Approaching/Departuring Angle | 18/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16LT 14PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP3Q130E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 96kW | 2970ml |
| D25TCIE1 | Kunming Yunnei Power Co., Ltd. | 105kW | 2499ml |
