| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 6800mm | ||
| Width | 2200mm | ||
| Height | 2780mm | ||
| Curb Weight | 4185kg | ||
| Gross Weight | 9300kg | ||
| Seats | 3 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | HFC1091P91K5C5ZV | ||
| Front/Rear Overhang | 1085/1900mm | ||
| Number of Leaf Springs | 8/6+6,9/6+6,9/12+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3815,3365mm | ||
| Axle Load | 2900/6400kg | ||
| Front Wheel Track | 1700mm | ||
| Rear Wheel Track | 1600mm | ||
| Approaching/Departuring Angle | 25.9/16° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 215/75R17.5 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP3Q130E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 96kW | 2970ml |
