| Basic Information | |||
| Usage | Fire Extinguishing Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 9270mm | ||
| Width | 2550mm | ||
| Height | 3620mm | ||
| Curb Weight | 18475kg | ||
| Gross Weight | 19000kg | ||
| Seats | 2+4+1 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | ZZ2257N4657E1X | ||
| Front/Rear Overhang | 1602/2348mm | ||
| Number of Leaf Springs | 9/12,4/12 | ||
| Number of Axles | 3 | ||
| Wheelbase | 3800+1400,4000+1400,4300+1400,4600+1400mm | ||
| Axle Load | 5800/6600/6600kg | ||
| Front Wheel Track | 2087mm | ||
| Rear Wheel Track | 2087/2087mm | ||
| Approaching/Departuring Angle | 23/11° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 14.00R20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D10.28-50 | China National Heavy Duty Truck Group Co., Ltd. | 206kW | 9726ml |
| D10.31-50 | China National Heavy Duty Truck Group Co., Ltd. | 228kW | 9726ml |
| D10.34-50 | China National Heavy Duty Truck Group Co., Ltd. | 249kW | 9726ml |
| D10.38-50 | China National Heavy Duty Truck Group Co., Ltd. | 276kW | 9726ml |
| MC11.32-50 | China National Heavy Duty Truck Group Co., Ltd. | 238kW | 10518ml |
| MC11.36-50 | China National Heavy Duty Truck Group Co., Ltd. | 268kW | 10518ml |
| MC11.40-50 | China National Heavy Duty Truck Group Co., Ltd. | 297kW | 10518ml |
