Taian Wuyue TAZ5315ZLJN Garbage Dump Truck

Basic Information
Usage	Refuse Collector
Fuel Type	Diesel
Emission Standard	GB17691-2005 national Ⅴ emission standards
Length	9980,10080,10280,9830,9930,10215mm
Width	2496,2550mm
Height	3450,3800mm
Curb Weight	15500kg
Gross Weight	31000kg
Seats	2
Max Speed	80km/h
Chassis
Chassis Model	ZZ3317V386GE1
Front/Rear Overhang	1500/1655,1500/1755,1500/1955,1500/1630,1500/1730,1500/2015,1500/2040,1500/1780,1500/1805,1500/1880,1500/1905,1500/2080mm
Number of Leaf Springs	4/4/12,11/11/12,11/11/10,4/4/-,11/11/-
Number of Axles	4
Wheelbase	1950+2525+1350,1950+2825+1350,1950+3025+1350,1950+3225+1350,1950+3525+1350,1950+3825+1350,1800+2525+1350,1800+2500+1400,1800+2825+1350,1800+2800+1400,1800+3025+1350,1800+3000+1400,1800+3225+1350,1800+3200+1400,1800+3525+1350,1800+3500+1400,1800+mm
Axle Load	6500/7000/17500(two axles)kg
Front Wheel Track	2022/2022,2041/2041mm
Rear Wheel Track	1860/1860mm
Approaching/Departuring Angle	17/21°
Tire
Number of Tires	12
Tire	11.00R20,12.00R20 18PR,12R22.5,295/80R22.5,315/80R22.5 18PR
Engine
Model	Brand	Power	Displacement
MC09.38-50	China National Heavy Duty Truck Group Co., Ltd.	276kW	8765ml
MC09.40-50	China National Heavy Duty Truck Group Co., Ltd.	294kW	8765ml
MC11.40-50	China National Heavy Duty Truck Group Co., Ltd.	297kW	10518ml
MC11.44-50	China National Heavy Duty Truck Group Co., Ltd.	327kW	10518ml
WP8.340E51	Weichai Power Co., Ltd.	250kW	7800ml
WP10H400E50	Weichai Power Co., Ltd.	294kW	9500ml
