| Basic Information | |||
| Usage | Street Sprinkler | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 7750,8300mm | ||
| Width | 2500mm | ||
| Height | 3200mm | ||
| Curb Weight | 6405kg | ||
| Gross Weight | 15800kg | ||
| Seats | 3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | EQ1160GD5DJ | ||
| Front/Rear Overhang | 1440/2360,1250/2550mm | ||
| Number of Leaf Springs | 9/12+10,8/10+7,8/10+8,7/9+6,11/11+10,9/10+8 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3950,4500,5100,4700,4200,5600,5700,6300mm | ||
| Axle Load | 5800/10000kg | ||
| Front Wheel Track | 1900,1880,1810,1940mm | ||
| Rear Wheel Track | 1860,1800,1800,1860,1830mm | ||
| Approaching/Departuring Angle | 25/18,23/17° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 9.00-20 16PR,10.00-20 16PR,10.00R20 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISD180 50 | Dongfeng Cummins Engine Co., Ltd. | 132kW | 4500ml |
| YC6JA180-50 | Guangxi Yuchai Machinery Co., Ltd. | 132kW | 6870ml |
| ISD190 50 | Dongfeng Cummins Engine Co., Ltd. | 144kW | 6700ml |
| ISB170 50 | Dongfeng Cummins Engine Co., Ltd. | 125kW | 5900ml |
| ISB190 50 | Dongfeng Cummins Engine Co., Ltd. | 140kW | 5900ml |
| ISB210 50 | Dongfeng Cummins Engine Co., Ltd. | 155kW | 5900ml |
| YC4E160-56 | Guangxi Yuchai Machinery Co., Ltd. | 118kW | 4260ml |
| YC4S150-50 | Guangxi Yuchai Machinery Co., Ltd. | 110kW | 3767ml |
| EQH180-52 | Dongfeng Commercial Vehicle Co., Ltd. | 132kW | 4752ml |
| WP4.1Q160E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 115kW | 4088ml |
| ISB180 50 | Dongfeng Cummins Engine Co., Ltd. | 132kW | 5900ml |
| YC4S160-50 | Guangxi Yuchai Machinery Co., Ltd. | 118kW | 3767ml |
| ISB220 50 | Dongfeng Cummins Engine Co., Ltd. | 162kW | 5900ml |
