| Main Beam Material | T700/AT BUYER REQUEST(SUCH AS Q235 #16) |
| Main Beam Middle Plate Thickness | 5mm |
| Main Beam Upper Plate Thickness | 8mm |
| Main Beam Lower Plate Thickness | 10mm |
| Main Beam Height | 490mm |
| Plate board | 1.8mm |
| Side Beam | 14#G Type |
| Side Material | T700/AT BUYER REQUEST(SUCH AS Q235 #16) |
| Axles Type | 13tons |
| Axles Brand | Fuwa/BPW/FENBAO/TAINCHI/AT BUYER REQUEST |
| Tire Brand | Chaoyang/Double Coin/Linglong/AT BUYER REQUEST |
| Rim Type/Material | R22.5 Steel/Aluminium Alloy |
| Leaf Spring Type Suspension | 90mm*13mm*10/Other |
| King Pin Type/Brand | 50#/90# JOST/Other |
| Landing Gear Type/Brand | 28tons Fuwa/Jost/Other |
| Tool Box | 2m/Aluminium Alloy |
| Side Protection | Aluminium Alloy |
| Brake System | Double Line Brake System |
| Brake Air Chamber | Four double and Two single Brake air chamber |
| ABS | Kemi/WEIBOKE/AT BUYER REQUEST |
| Electrical system | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)Tail lamp with turn signal, brake light & reflector, side lamp etc.One set 6-core standard Cable. |
| Packing | Complete Chassis sand blasting to clean rust, 1 coat of anti-rust prime,2 coats of final paint |
| Delivery way | Transfer to Qingdao Port, and carry by ro-ro ship or bulk cargo ship or container, the freight cost depends on the volume,We will arrange the most cost-effective transportation mode |
| All trailers and trucks will be polished with wax before shipping. | |
