| Basic Information | |||
| Usage | Snow Sweeper | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5995mm | ||
| Width | 2000mm | ||
| Height | 2380mm | ||
| Curb Weight | 3230kg | ||
| Gross Weight | 7360kg | ||
| Seats | 2 | ||
| Max Speed | 99km/h | ||
| Chassis | |||
| Chassis Model | EQ1070SJ3BDF | ||
| Front/Rear Overhang | 1040/1647mm | ||
| Number of Leaf Springs | 6/6+5 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3308,2800mm | ||
| Axle Load | 2640/4720kg | ||
| Front Wheel Track | 1503,1485,1519,1595mm | ||
| Rear Wheel Track | 1494,1516,1540mm | ||
| Approaching/Departuring Angle | 20/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00-16,7.00R16 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CY4BK551 | Dongfeng Chaoyang Diesel Co., Ltd. | 75kW | 3707ml |
| YC4FA115-50 | Guangxi Yuchai Machinery Co., Ltd. | 85kW | 2982ml |
| 4B2-115C50 | Anhui Quanchai Power Co., Ltd. | 85kW | 2545ml |
| ZD30D13-5N | Dongfeng Light Engine Co., Ltd. | 96kW | 2953ml |
| D28D11-5DA | Dongfeng Light Engine Co., Ltd. | 85kW | 2771ml |
| 4DW93-84E5 | FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant | 64kW | 2540ml |
| YN27CRE1 | Kunming Yunnei Power Co., Ltd. | 70kW | 2672ml |
| YN33CRE1 | Kunming Yunnei Power Co., Ltd. | 85kW | 3298ml |
| SD4D25R-70 | Jiangsu Sida Power Machinery Group Co., Ltd. | 70kW | 2545ml |
| 4DX23-120E5 | FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant | 90kW | 3857ml |
| D25TCIE2 | Kunming Yunnei Power Co., Ltd. | 96kW | 2499ml |
| 4F20TCIE5 | Changchai Co., Ltd. | 70kW | 1995ml |
| 4DW94-95E5 | FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant | 72kW | 2720ml |
| YCD4N4S-110 | Guangxi Yuchai Machinery Co., Ltd. | 80kW | 2799ml |
| WP2.3Q110E50 | Weichai Power Yangzhou Diesel Engine Co., Ltd. | 81kW | 2290ml |
