| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5995mm | ||
| Width | 2150mm | ||
| Height | 2950mm | ||
| Curb Weight | 4300kg | ||
| Gross Weight | 4495kg | ||
| Seats | 3 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | CA1047P40K50L1BE5A84 | ||
| Front/Rear Overhang | 1150/1545mm | ||
| Number of Leaf Springs | 3/4+3,7/7+3,3/7+9,3/7+3,3/3+3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3300mm | ||
| Axle Load | 1950/2545kg | ||
| Front Wheel Track | 1510mm | ||
| Rear Wheel Track | 1475mm | ||
| Approaching/Departuring Angle | 21/16° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.50-16,6.50R16,7.00-16,7.00R16 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4B2-95C50 | Anhui Quanchai Power Co., Ltd. | 70kW | 2545ml |
| WP2.1Q95E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 70kW | 2088ml |
| 4B2-110C50 | Anhui Quanchai Power Co., Ltd. | 80kW | 2545ml |
| WP2.3Q110E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 81kW | 2290ml |
| CA4DC3-12E5-30 | FAW Jiefang Dalian Diesel Co., Ltd. | 91kW | 3000ml |
| WP2.3NQ120E50 | Weichai Power Co., Ltd. | 88kW | 2290ml |
| WP2.3NQ130E50 | Weichai Power Co., Ltd. | 96kW | 2290ml |
| CA4DB1-11E5 | FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant | 80kW | 2200ml |
| CA4DB1-13E5 | FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant | 95kW | 2210ml |
