| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 5341,5501mm | ||
| Width | 2032mm | ||
| Height | 2407,2537,2667mm | ||
| Curb Weight | 2350kg | ||
| Gross Weight | 3300kg | ||
| Seats | 3-7 | ||
| Max Speed | 156km/h | ||
| Chassis | |||
| Chassis Model | JX6533P-M5, Jiangling Motors Corporation Ltd. | ||
| Front/Rear Overhang | 1014/1027,1014/1187mm | ||
| Number of Leaf Springs | -/1,-/2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3300mm | ||
| Axle Load | 1510/1790kg | ||
| Front Wheel Track | 1736mm | ||
| Rear Wheel Track | 1720mm | ||
| Approaching/Departuring Angle | 21/23,21/20° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 215/75R16LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ECOBOOST4G20B5L | Jiangling Motors Corporation Ltd. | 149kW | 1997ml |
