| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5995mm | ||
| Width | 2200,2150,2100mm | ||
| Height | 2995mm | ||
| Curb Weight | 2870kg | ||
| Gross Weight | 4495kg | ||
| Seats | 3，2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | BJ1049V8JEA-F1 | ||
| Front/Rear Overhang | 1120/1515mm | ||
| Number of Leaf Springs | 3+1/6+7,3/7+6,3/8+6,3/4+2,3/5+2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3360mm | ||
| Axle Load | 1800/2695kg | ||
| Front Wheel Track | 1530,1730,1590mm | ||
| Rear Wheel Track | 1485,1590,1615,1800mm | ||
| Approaching/Departuring Angle | 22/16° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00-16 8PR,7.00R16 8PR,7.50-16 6PR,7.50R16 6PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISF2.8s5R117 | Beijing Foton Cummins Engine Corporation | 87kW | 2780ml |
| ISF3.8s5141 | Beijing Foton Cummins Engine Corporation | 105kW | 3760ml |
| 4J28TC3 | Foton Motor Co., Ltd. | 81kW | 2771ml |
| 4J28TC5 | Foton Motor Co., Ltd. | 81kW | 2771ml |
| ISF2.8s5129T | Beijing Foton Cummins Engine Corporation | 96kW | 2780ml |
| ISF2.8s5F130 | Beijing Foton Cummins Engine Corporation | 96kW | 2780ml |
| 4B2-115C50 | Anhui Quanchai Power Co., Ltd. | 85kW | 2545ml |
