| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5995mm | ||
| Width | 2095mm | ||
| Height | 2900mm | ||
| Curb Weight | 2920kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2,3 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | EQ1041SJ3BDFWXP | ||
| Front/Rear Overhang | 1040/1647mm | ||
| Number of Leaf Springs | 6/6+5 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3308mm | ||
| Axle Load | 1800/2695kg | ||
| Front Wheel Track | 1503,1485,1441mm | ||
| Rear Wheel Track | 1494,1458mm | ||
| Approaching/Departuring Angle | 20/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00-16 8PR,7.00R16 8PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CY4BK551 | Dongfeng Chaoyang Diesel Co., Ltd. | 75kW | 3707ml |
| YC4FA115-50 | Guangxi Yuchai Machinery Co., Ltd. | 85kW | 2982ml |
| D28D11-5DA | Dongfeng Light-duty Engine Co., Ltd. | 85kW | 2771ml |
| D25TCIE2 | Kunming Yunnei Power Co., Ltd. | 96kW | 2499ml |
| YN33CRE1 | Kunming Yunnei Power Co., Ltd. | 85kW | 3298ml |
| 4DW94-95E5 | FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant | 72kW | 2720ml |
