Basic Information | |||
Usage | Vacuum Sweeper | ||
Fuel Type | Diesel | ||
Emission Standard | GB3847-2005,GB17691-2005 national V emission standards | ||
Length | 8350,8050,7850,7550,7150mm | ||
Width | 2500mm | ||
Height | 3060mm | ||
Curb Weight | 11070kg | ||
Gross Weight | 15800kg | ||
Seats | 3 | ||
Max Speed | 98km/h | ||
Chassis | |||
Chassis Model | DFL1160BX1V | ||
Front/Rear Overhang | 1430/1920mm | ||
Number of Leaf Springs | 7/9+6,8/10+8,10/11+10 | ||
Number of Axles | 2 | ||
Wheelbase | 3800,4200,4500,4700,5000,3950,5600mm | ||
Axle Load | 5600/10200kg | ||
Front Wheel Track | 1880,1900,1920mm | ||
Rear Wheel Track | 1800,1860,1820mm | ||
Approaching/Departuring Angle | 20/12° | ||
Tire | |||
Number of Tires | 6 | ||
Tire | 9.00R20 16PR,10.00-20 16PR,10.00-20 18PR,10.00R20 14PR,10.00R20 16PR,10.00R20 18PR,10R22.5 16PR,275/80R22.5,275/70R22.5 16PR,275/70R22.5 18PR,295/80R22.5 | ||
Engine | |||
Model | Brand | Power | Displacement |
ISD210 50 | Dongfeng Cmuuins Engine Co., Ltd. | 155kW | 6700ml |
ISD190 50 | Dongfeng Cmuuins Engine Co., Ltd. | 144kW | 6700ml |
ISD180 50 | Dongfeng Cmuuins Engine Co., Ltd. | 132kW | 4500ml |
EQH180-52 | Dongfeng Trucks Co., Ltd. | 132kW | 4752ml |
EQH180-53 | Dongfeng Trucks Co., Ltd. | 132kW | 4752ml |
ISB180 50 | Dongfeng Cmuuins Engine Co., Ltd. | 132kW | 5900ml |
ISD270 50 | Dongfeng Cmuuins Engine Co., Ltd. | 198kW | 6700ml |
ISB210 50 | Dongfeng Cmuuins Engine Co., Ltd. | 155kW | 5900ml |
ISB190 50 | Dongfeng Cmuuins Engine Co., Ltd. | 140kW | 5900ml |
