| Basic Information | |||
| Usage | Road-block Removal Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5995mm | ||
| Width | 2300mm | ||
| Height | 2200mm | ||
| Curb Weight | 3700kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2 | ||
| Max Speed | 98km/h | ||
| Chassis | |||
| Chassis Model | QL1040A6HAY | ||
| Front/Rear Overhang | 1015/1620 mm | ||
| Number of Leaf Springs | 3/3+2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3360mm | ||
| Axle Load | 1805/2690kg | ||
| Front Wheel Track | 1377mm | ||
| Rear Wheel Track | 1425mm | ||
| Approaching/Departuring Angle | 24/13° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16 8PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4KH1CN5LS | Qingling Isuzu (Chongqing) Engine Co., Ltd. | 72，96，85kW | 2999ml |
| 4KH1CN5HD | Qingling Isuzu (Chongqing) Engine Co., Ltd. | 2999ml | |
| 4KH1CN5MD | Qingling Isuzu (Chongqing) Engine Co., Ltd. | 2999ml | |
