| Basic Information | |||
| Usage | Ambulance | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 4744,4944mm | ||
| Width | 1974mm | ||
| Height | 2280,2390mm | ||
| Curb Weight | 2180kg | ||
| Gross Weight | 2830kg | ||
| Seats | 3-8 | ||
| Max Speed | 140km/h | ||
| Chassis | |||
| Chassis Model | JX6471PA-L5, Jiangling Motors Group Co., Ltd. | ||
| Front/Rear Overhang | 1026/883,1026/1083mm | ||
| Number of Leaf Springs | -/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2835mm | ||
| Axle Load | 1260/1570kg | ||
| Front Wheel Track | 1692mm | ||
| Rear Wheel Track | 1700mm | ||
| Approaching/Departuring Angle | 19/18° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 215/70R15LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4G69S4N | Shenyang Aerospace Sanling Automobile Engine Manufacture Co., Ltd. | 100kW | 2378ml |
