| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards | ||
| Length | 11965mm | ||
| Width | 2495mm | ||
| Height | 3065mm | ||
| Curb Weight | 12500kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | ND1250BD5J6Z01 second-class, Beiben Trucks Group Co., Ltd. | ||
| Front/Rear Overhang | 1435/3130mm | ||
| Number of Leaf Springs | 13/13 | ||
| Number of Axles | 3 | ||
| Wheelbase | 5950+1450mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 1995mm | ||
| Rear Wheel Track | 1800/1800mm | ||
| Approaching/Departuring Angle | 17/10° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 12.00R20 16PR,11.00R20 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10.350E53 | Weichai Holding Group Co., Ltd. | 257kW | 9726ml |
