| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10015,11715,11850mm | ||
| Width | 2550mm | ||
| Height | 3540,3805mm | ||
| Curb Weight | 10800kg | ||
| Gross Weight | 25500kg | ||
| Seats | 2 | ||
| Max Speed | 89km/h | ||
| Chassis | |||
| Chassis Model | ND1260BD5J7Z17 | ||
| Front/Rear Overhang | 1515/3500,1515/2485,1515/2400,1515/3035mm | ||
| Number of Leaf Springs | 2/- | ||
| Number of Axles | 3 | ||
| Wheelbase | 4750+1350,5350+1350,6500+1350,5950+1350mm | ||
| Axle Load | 6500/19000(two axles)kg | ||
| Front Wheel Track | 2045,2063mm | ||
| Rear Wheel Track | 1850/1850,1870/1870mm | ||
| Approaching/Departuring Angle | 7/7,7/10,7/11,7/8° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 295/60R22.5 18PR,295/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP13.500E501 | Weichai Holding Group Co., Ltd. | 368kW | 12540ml |
