| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Natural gas | ||
| Emission Standard | GB 11340-2005,GB17691-2005 national Ⅴ emission standards, GB18285-2005 | ||
| Length | 10885,11095mm | ||
| Width | 2500,2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 16750kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2,3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | ND1310DG5J7Z00 | ||
| Front/Rear Overhang | 1515/2870,1515/2780mm | ||
| Number of Leaf Springs | 12/12/13 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+3100+1450,1950+3400+1450mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2045/2045mm | ||
| Rear Wheel Track | 1872/1872mm | ||
| Approaching/Departuring Angle | 16/15° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00-20 18PR,11.00R20 18PR,12.00-20 16PR,12.00R20 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10NG336E50 | Weichai West Port New Energy Power Co., Ltd. | 247kW | 9726ml |
| WP12NG330E50 | Weichai West Port New Energy Power Co., Ltd. | 243kW | 11596ml |
| WP12NG350E50 | Weichai West Port New Energy Power Co., Ltd. | 257kW | 11596ml |
| WP12NG380E50 | Weichai West Port New Energy Power Co., Ltd. | 280kW | 11596ml |
| YC6MK340N-50 | YC Diesel Co., Ltd. | 250kW | 10338ml |
| YC6MK375N-50 | YC Diesel Co., Ltd. | 276kW | 10338ml |
