| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Natural gas | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB18285-2005,GB11340-2005 | ||
| Length | 9970mm | ||
| Width | 2500,2550mm | ||
| Height | 3980mm | ||
| Curb Weight | 15155kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2,3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | ND1250BG5J7Z01 | ||
| Front/Rear Overhang | 1515/2905mm | ||
| Number of Leaf Springs | 10/13 | ||
| Number of Axles | 3 | ||
| Wheelbase | 4100+1450mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 2045mm | ||
| Rear Wheel Track | 1872/1872mm | ||
| Approaching/Departuring Angle | 16/20° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00R20 18PR,12.00R20 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP12NG350E50 | Weichai West Port New Energy Power Co., Ltd. | 257kW | 11596ml |
