| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 9250,9300mm | ||
| Width | 2500mm | ||
| Height | 3980mm | ||
| Curb Weight | 13785kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2,3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | ND12505B38J7 | ||
| Front/Rear Overhang | 1515/2535mm | ||
| Number of Leaf Springs | 10/13,13/13 | ||
| Number of Axles | 3 | ||
| Wheelbase | 3850+1350,3800+1450mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 1995,2045mm | ||
| Rear Wheel Track | 1800/1800,1872/1872mm | ||
| Approaching/Departuring Angle | 16/22° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 315/80R22.5 16PR,11.00-20 18PR,11.00R20 16PR,12.00-20 16PR,12.00R20 14PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10.336E40 | Weichai Holding Group Co., Ltd. | 247kW | 9726ml |
| WP12.375E40 | Weichai Holding Group Co., Ltd. | 276kW | 11596ml |
