| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards | ||
| Length | 10150mm | ||
| Width | 2550mm | ||
| Height | 3980mm | ||
| Curb Weight | 14200kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | ND3310DD6J7Z01 | ||
| Front/Rear Overhang | 1515/2435mm | ||
| Number of Leaf Springs | 4/4/5,10/10/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+2550+1350,1950+2850+1350,1950+3150+1350,1950+3450+1350,1950+3100+1450,1950+3400+1450,1950+2900+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2004/2004mm | ||
| Rear Wheel Track | 1874/1874mm | ||
| Approaching/Departuring Angle | 17/14° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 12.00R20 18PR,11.00R20 18PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10H350E62 | Weichai Holding Group Co., Ltd. | 257kW | 9500ml |
| WP10H375E62 | Weichai Holding Group Co., Ltd. | 276kW | 9500ml |
| WP12.430E62 | Weichai Holding Group Co., Ltd. | 316kW | 11596ml |
| WP12.460E62 | Weichai Holding Group Co., Ltd. | 338kW | 11596ml |
| WP8.350E61 | Weichai Holding Group Co., Ltd. | 257kW | 7800ml |
| WP8.320E61 | Weichai Holding Group Co., Ltd. | 235kW | 7800ml |
