| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 9925,9995mm | ||
| Width | 2550mm | ||
| Height | 3980mm | ||
| Curb Weight | 15800kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2,3 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | ND1250BD5J6Z03 | ||
| Front/Rear Overhang | 1435/2940,1435/2810mm | ||
| Number of Leaf Springs | 10/13 | ||
| Number of Axles | 3 | ||
| Wheelbase | 4100+1450,4300+1450mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 2004,1996mm | ||
| Rear Wheel Track | 1878/1878,1904/1904mm | ||
| Approaching/Departuring Angle | 17/21,17/22° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00R20 18PR,12.00R20 16PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10.350E53 | Weichai Holding Group Co., Ltd. | 257kW | 9726ml |
| WP12.375E50 | Weichai Holding Group Co., Ltd. | 276kW | 11596ml |
| WP10H375E50 | Weichai Holding Group Co., Ltd. | 276kW | 9500ml |
