| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11285,11765mm | ||
| Width | 2550mm | ||
| Height | 3980mm | ||
| Curb Weight | 18760kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | ND1310DD5J7Z02 | ||
| Front/Rear Overhang | 1515/2970,1515/3150mm | ||
| Number of Leaf Springs | 12/12/13 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+3100+1450,1950+3400+1450,1950+3700+1450mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2042/2042mm | ||
| Rear Wheel Track | 1878/1878,1904/1904mm | ||
| Approaching/Departuring Angle | 17/22,17/18° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 12.00R20 18PR,11.00R20 18PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP12.375E50 | Weichai Holding Group Co., Ltd. | 276kW | 11596ml |
| WP10H375E50 | Weichai Holding Group Co., Ltd. | 276kW | 9500ml |
| WP10H400E50 | Weichai Holding Group Co., Ltd. | 294kW | 9500ml |
