Basic Information | |||
Usage | Refuse Collector | ||
Fuel Type | Diesel | ||
Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
Length | 8355,8455,8785,8965,9035mm | ||
Width | 2550mm | ||
Height | 3450mm | ||
Curb Weight | 12500kg | ||
Gross Weight | 25000kg | ||
Seats | 2 | ||
Max Speed | 80km/h | ||
Chassis | |||
Chassis Model | ND3250BD5J7Z06 | ||
Front/Rear Overhang | 1515/1590,1515/1690,1515/1720,1515/1900,1515/1970mm | ||
Number of Leaf Springs | 10/13 | ||
Number of Axles | 3 | ||
Wheelbase | 3800+1450,4100+1450mm | ||
Axle Load | 7000/18000(two axles)kg | ||
Front Wheel Track | 2004mm | ||
Rear Wheel Track | 1878/1878,1904/1904mm | ||
Approaching/Departuring Angle | 17/25° | ||
Tire | |||
Number of Tires | 10 | ||
Tire | 12.00R20 16PR,11.00R20 18PR,12R22.5 18PR,315/80R22.5 18PR/315/80R22.5 16PR,295/80R22.5 18PR | ||
Engine | |||
Model | Brand | Power | Displacement |
WP12.375E50 | Weichai Holding Group Co., Ltd. | 276kW | 11596ml |
WP10.350E53 | Weichai Holding Group Co., Ltd. | 257kW | 9726ml |
