| Model | CLW5160GXET4 |
| Gross Weight | 15900 (kg) |
| Volume | 9.0 (cubic meter) |
| Rated Load | 7780 (Kg) |
| Curb Weight | 7925 (kg) |
| Dimensions | 8090,7890,7600,7800×2470×3180 (mm) |
| Approaching/Departuring Angle | 23/14,20/14(°) |
| Front/Rear Overhang | 1250/2140,1450/2140,1250/2400,1450/2400(mm) |
| Number of Axles | 2 |
| Wheelbase | 3800,3950,4200,4500,4700,5100 (mm) |
| Axle Load | 5950/9950 (kg) |
| Max Speed | 90 (km/h) |
| Chassis type | EQ1168VFJ1 |
| Number of Tires | 6 |
| Number of Leaf Spring | 9/10+8 |
| Tire | 9.00-20,9.00R20,10.00-20,10.00R20 |
| Front Wheel Track | 1920,1960(mm) |
| Rear Wheel Track | 1860 (mm) |
| Chassis Discharge Standard | GB3847-2005, GB17691-2005 National IV Emission Standards |
| Fuel Type | Diesel |
| Engine Model | YC6J180-46, YC6J160-46, ISB170 40, ISB190 40, YC4E160-46 |
| Engine Displacement | 4260 - 6494 (ml) |
| Engine Max Power | 118 - 140 (kw) |
