| Model | CLW5120GXET4 |
| Gross Weight | 12490 (kg) |
| Volume | 6.99 (cubic meter) |
| Rated Load | 6000 (Kg) |
| Curb Weight | 6295 (kg) |
| Dimensions | 7600×2470×2800 (mm) |
| Approaching/Departuring Angle | 30/15(°) |
| Front/Rear Overhang | 1250/2400(mm) |
| Number of Axles | 2 |
| Wheelbase | 3650,3800,3950,4100,4500 (mm) |
| Axle Load | 4990/7500 (kg) |
| Max Speed | 90 (km/h) |
| Chassis type | EQ1128GLJ |
| Number of Tires | 6 |
| Number of Leaf Spring | 9/11+8,8/10+8,8/11+8,9/10+8 |
| Tire | 9.00-20 16PR,9.00R20 16PR,10.00-20 14PR,10.00R20 14PR |
| Front Wheel Track | 1810,1900,1750(mm) |
| Rear Wheel Track | 1800,1750,1860 (mm) |
| Chassis Discharge Standard | GB17691-2005 National IV Emission Standards, GB3847-2005 |
| Fuel Type | Diesel |
| Engine Model | YC6J180-42, ISDe180 40, ISB3.9-160E41A, ISB170 40, YC6J160-46, YC4E160-42, YC4EG180-40, 4DX23-140E4, YCD4J2S-150 |
| Engine Displacement | 3857 - 6500 (ml) |
| Engine Max Power | 105 - 132 (kw) |
