| Model | CLW5071GXE4 |
| Gross Weight | 7300 (kg) |
| Volume | 3.84(cubic meter) |
| Rated Load | 3365,3300 (Kg) |
| Curb Weight | 3805 (kg) |
| Dimensions | 5995×2000×2500(mm) |
| Approaching/Departuring Angle | 19/13(°) |
| Front/Rear Overhang | 1032/1663(mm) |
| Number of Axles | 2 |
| Wheelbase | 3300(mm) |
| Axle Load | 2920/4380 (kg) |
| Max Speed | 95(km/h) |
| Chassis type | DFA1070SJ35D6 |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/9+5,6/8+4,6/6+5 |
| Tire | 7.00-16 14PR,7.00R16 14PR |
| Front Wheel Track | 1506,1404,1500,1441,1586(mm) |
| Rear Wheel Track | 1466,1458,1520,1500,1530 (mm) |
| Chassis Discharge Standard | GB3847-2005, GB17691-2005 National IV Emission Standards |
| Fuel Type | Diesel |
| Engine Model | 4B28BTCI, SD4BW754U, YN33CRD2, Y4102-CE4F, YC4FA90-40, D28D10-4DA, 4F20ATCI, CY4T75-CE4, 4DW93-84E4, YN27CRD1, 4DW93-95E4 |
| Engine Displacement | 1995- 3856 (ml) |
| Engine Max Power | 60 - 75 (kw) |
