| Model | CLW5040GXEB4 |
| Gross Weight | 3985 (kg) |
| Volume | 2.03(cubic meter) |
| Rated Load | 1550 (Kg) |
| Curb Weight | 2305 (kg) |
| Dimensions | 5210,5310,5510×1720×2350(mm) |
| Approaching/Departuring Angle | 18/22(°) |
| Front/Rear Overhang | 1185/1325(mm) |
| Number of Axles | 2 |
| Wheelbase | 2700,2800,3000(mm) |
| Axle Load | 1515/2470(kg) |
| Max Speed | 90 (km/h) |
| Chassis type | BJ1046V9JB5-H1 |
| Number of Tires | 6 |
| Number of Leaf Spring | 3/5,3/5+3,3/5+1 |
| Tire | 6.00-14,6.00-15,185R15 6PR |
| Front Wheel Track | 1385(mm) |
| Rear Wheel Track | 1280(mm) |
| Chassis Discharge Standard | GB17691-2005 |
| Fuel Type | Diesel |
| Engine Model | 4B1-82C40, 4A1-68C40, 4L18CF, YZ4DC1-40, 4L22CF |
| Engine Displacement | 1809 - 2156(ml) |
| Engine Max Power | 50-60(kw) |
