| Model | CLW5070TSLD5 |
| Gross Weight | 7360(kg) |
| Rated Load | 2190 (Kg) |
| Curb Weight | 5040 (kg) |
| Dimensions | 6200,5950×2000×2590,2380 (mm) |
| Approaching/Departuring Angle | 20/12(°) |
| Front/Rear Overhang | 1040/1852,1040/1602 (mm) |
| Number of Axles | 2 |
| Wheelbase | 3308,2800 (mm) |
| Axle Load | 2640/4720 (kg) |
| Max Speed | 99 (km/h) |
| Chassis type | EQ1070SJ3BDF |
| Number of Tires | 6 |
| Number of Leaf Spring | 6/6+5,3/3+3 |
| Tire | 7.00-16,7.00R16 |
| Front Wheel Track | 1503,1485,1519,1595 (mm) |
| Rear Wheel Track | 1494,1516,1540,1586 (mm) |
| Chassis Discharge Standard | GB17691-2005 National V Emission Standards, GB3847-2005 |
| Fuel Type | Diesel |
| Engine Model | CY4BK551, YC4FA115-50, 4B2-115C50, ZD30D13-5N, D28D11-5DA, 4DW93-84E5, YN27CRE1, YN33CRE1, SD4D25R-70, 4DX23-120E5, D25TCIE2, 4F20TCIE5, 4DW94-95E5, YCD4N4S-110, WP2.3Q110E50 |
| Engine Displacement | 1995 - 3857 (ml) |
| Engine Max Power | 64 - 96 (kw) |
