| Model | CLW5182TXSD5 |
| Gross Weight | 18000(kg) |
| Rated Load | 7155 (Kg) |
| Curb Weight | 10650(kg) |
| Dimensions | 8580,7880,7550×2500×3120(mm) |
| Approaching/Departuring Angle | 19/12(°) |
| Front/Rear Overhang | 1230/2150,1230/2370(mm) |
| Number of Axles | 2 |
| Wheelbase | 4500,5200,3950(mm) |
| Axle Load | 6500/11500(kg) |
| Max Speed | 90(km/h) |
| Chassis type | EQ1181LJ9BDE |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/10+7 |
| Tire | 10.00R20,295/80R22.5,275/80R22.5 |
| Front Wheel Track | 1923,1949(mm) |
| Rear Wheel Track | 1865 (mm) |
| Chassis Discharge Standard | GB17691-2005 National V Emission Standards, GB3847-2005 |
| Fuel Type | Diesel |
| Engine Model | YC4EG185-50, ISB180 50, ISB210 50, YC6JA180-50, YC4S160-50, YC4S170-50 |
| Engine Displacement | 3767 - 6870 (ml) |
| Engine Max Power | 118 - 155(kw) |
