| Model | CLW5160TXSD5 |
| Gross Weight | 15800(kg) |
| Rated Load | 4255 (Kg) |
| Curb Weight | 11350(kg) |
| Dimensions | 8580,8280,8050×2490×3100(mm) |
| Approaching/Departuring Angle | 20/13(°) |
| Front/Rear Overhang | 1430/2150,1430/1920(mm) |
| Number of Axles | 2 |
| Wheelbase | 3800,4200,4500,4700,5000,3950,5600(mm) |
| Axle Load | 5600/10200(kg) |
| Max Speed | 98(km/h) |
| Chassis type | DFL1160BX1V |
| Number of Tires | 6 |
| Number of Leaf Spring | 7/9+6,8/10+8,10/11+10,11/11+10 |
| Tire | 9.00R20 16PR,10.00-20 16PR,10.00-20 18PR,10.00R20 14PR,10.00R20 16PR,10.00R20 18PR,10R22.5 16PR,275/80R22.5,275/70R22.5 16PR,275/70R22.5 18P |
| Front Wheel Track | 1880,1900,1920,1815(mm) |
| Rear Wheel Track | 1800,1860,1820 (mm) |
| Chassis Discharge Standard | GB3847-2005, GB17691-2005 National V Emission Standards |
| Fuel Type | Diesel |
| Engine Model | ISD21050 | ISD19050 | ISD18050 | EQH180-52 | EQH180-53 | ISB18050 | ISD27050 | ISB21050 | ISB190 50 |
| Engine Displacement | 4500 - 6700 (ml) |
| Engine Max Power | 132 - 198(kw) |
