| Model | CLW5160TXC5 |
| Gross Weight | 15800 (kg) |
| Rated Load | 5605(Kg) |
| Curb Weight | 10000(kg) |
| Dimensions | 8450,8250,7950×2500×3100(mm) |
| Approaching/Departuring Angle | 20/12(°) |
| Front/Rear Overhang | 1430/2320 (mm) |
| Number of Axles | 2 |
| Wheelbase | 3800,4200,4500,4700,5000,3950,5600(mm) |
| Axle Load | 5600/10200(kg) |
| Max Speed | 98(km/h) |
| Chassis type | DFL1160BX1V |
| Number of Tires | 6 |
| Number of Leaf Spring | 7/9+6,8/10+8,10/11+10,11/11+10 |
| Tire | 9.00R20 16PR,10.00-20 16PR, 10.00-20 18PR,10.00R20 14PR,10.00R20 16PR,10.00R20 18PR,10R22.5 16PR,275/80R22.5,275/70R22.5 16PR,275/70R22.5 18P |
| Front Wheel Track | 1880,1900,1920,1815(mm) |
| Rear Wheel Track | 1800,1860,1820(mm) |
| Chassis Discharge Standard | GB3847-2005, GB17691-2005 National V Emission Standards |
| Fuel Type | Diesel |
| Engine Model | ISD210 50, ISD190 50, ISD180 50, EQH180-52, EQH180-53, ISB180 50, ISD270 50, ISB210 50, ISB190 50 |
| Engine Displacement | 4500 - 6700(ml) |
| Engine Max Power | 132 - 198(kw) |
