| Model | DLQ5160GPSL5 |
| Gross Weight | 15800 (kg) |
| Volume | 11.54 (cubic meter) |
| Rated Load | 8795(Kg) |
| Curb Weight | 6810(kg) |
| Dimensions | 7700,8200×2480×3180(mm) |
| Approaching/Departuring Angle | 21/18(°) |
| Front/Rear Overhang | 1250/2500,1250/2450,1440/2310,1440/2260(mm) |
| Number of Axles | 2 |
| Wheelbase | 3950,4500,5100,4700,4200,5600,5700(mm) |
| Axle Load | 5800/10000(kg) |
| Max Speed | 90(km/h) |
| Chassis type | EQ1160GD5DJ |
| Number of Tires | 6 |
| Number of Leaf Spring | 9/12+10,8/10+7,8/10+8,7/9+6,11/11+10,9/10+8 |
| Tire | 9.00-20 16PR,10.00-20 16PR,10.00R20 16PR |
| Front Wheel Track | 1900,1880,1810,1940(mm) |
| Rear Wheel Track | 1860,1800,1800,1860,1830(mm) |
| Chassis Discharge Standard | GB17691-2005 National V Emission Standards, GB3847-2005 |
| Fuel Type | Diesel |
| Engine Model | ISD180 50, YC6JA180-50, ISD190 50, ISB170 50, ISB190 50, ISB210 50, YC4E160-56, YC4S150-50, EQH180-52, WP4.1Q160E50, ISB180 50 |
| Engine Displacement | 3767 - 6870(ml) |
| Engine Max Power | 110 - 155(kw) |
