| Model | CLW5070GXED6 |
| Gross Weight | 7360(kg) |
| Volume | 4.63 (cubic meter) |
| Rated Load | 3530(Kg) |
| Curb Weight | 3700(kg) |
| Dimensions | 5995×2010×2500(mm) |
| Approaching/Departuring Angle | 27.7/12(°) |
| Front/Rear Overhang | 1055/1632(mm) |
| Number of Axles | 2 |
| Wheelbase | 2700,2950,3308(mm) |
| Axle Load | 2640/4720(kg) |
| Max Speed | 110(km/h) |
| Chassis type | EQ1075SJ3CDF |
| Number of Tires | 6 |
| Number of Leaf Spring | 6/6+5,3/3+3,5/4+3,6/4+3,6/5+2,6/3+3,3/6+5,3/3+2,2/2 |
| Tire | 7.00R16,7.00R16LT,7.00R16LT 14PR |
| Front Wheel Track | 1525,1519,1503,1613(mm) |
| Rear Wheel Track | 1498,1516,1586,1670,1650(mm) |
| Chassis Discharge Standard | GB17691-2018 National VI Emission Standards |
| Fuel Type | Diesel |
| Engine Model | CY4BK461, CA4DB1-11E6, CY4BK161, D20TCIF1, Q28-130E60, H20-120E60, CA4DB1-13E6, YCY24140-60, D20TCIF11, Q23-115E60, ZD30D16-6N, M9T-600 |
| Engine Displacement | 1999 - 3856(ml) |
| Engine Max Power | 81 - 120(kw) |
