| Model | CLW5180GSSD6 |
| Gross Weight | 18000(kg) |
| Volume | 10.83(cubic meter) |
| Rated Load | 10385,10320,10985,11050(Kg) |
| Curb Weight | 7485,6820(kg) |
| Dimensions | 8530,8400,8200,7650×2500×3200 (mm) |
| Approaching/Departuring Angle | 19/11(°) |
| Front/Rear Overhang | 1260/2270,1260/2440(mm) |
| Number of Axles | 2 |
| Wheelbase | 3600,3950,4500,4700,5000,5300,5600(mm) |
| Axle Load | 6500/11500(kg) |
| Max Speed | 89,105(km/h) |
| Chassis type | EQ1185LJ9CDE |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/10+7,8/- |
| Tire | 295/80R22.5 18PR,10.00R20 18PR,275/80R22.5 18PR |
| Front Wheel Track | 1862,1933,1949(mm) |
| Rear Wheel Track | 1806,1865(mm) |
| Chassis Discharge Standard | GB3847-2005, GB17691-2018 National VI Emission Standards |
| Fuel Type | Diesel |
| Engine Model | B6.2NS6B210, D4.5NS6B220, D4.0NS6B195, YCS04200-68, CY4SK761, B6.2NS6B230, YCY30165-60 |
| Engine Displacement | 2970 - 6200(ml) |
| Engine Max Power | 121 - 169 (kw) |
