| Model | CLW5160GPSL5 |
| Gross Weight | 15600(kg) |
| Volume | 10.08(cubic meter) |
| Rated Load | 9185,9120(Kg) |
| Curb Weight | 6285(kg) |
| Dimensions | 8520×2480×3000 (mm) |
| Approaching/Departuring Angle | 26/12(°) |
| Front/Rear Overhang | 1340/2480(mm) |
| Number of Axles | 2 |
| Wheelbase | 5100,4700,5700,6300(mm) |
| Axle Load | 5600/10000(kg) |
| Max Speed | 90(km/h) |
| Chassis type | LZ5161XXYM3ABT |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/9+5,11/12+9,3/4+3,2/2+1,3/3+2,2/9+5,3/9+5,7/7+8,3/9+7 |
| Tire | 9.00-20 16PR,9.00R20 16PR,275/70R22.5 16PR,275/70R22.5 18PR,10R22.5 16PR |
| Front Wheel Track | 1810,1916,1940(mm) |
| Rear Wheel Track | 1800(mm) |
| Chassis Discharge Standard | GB17691-2005 National V Emission Standards, GB3847-2005 |
| Fuel Type | Diesel |
| Engine Model | YC4EG160-50 | ISD16050 | YC4EG140-50 | YC4EG170-50 | YC4EG185-50 | ISD18050 | ISD20050 | YC4S160-50 | YC4EG200-50 | YC4S170-50 |
| Engine Displacement | 3767 - 4730(ml) |
| Engine Max Power | 105 - 147(kw) |
