| Model | CLW5160GPSD5 |
| Gross Weight | 15995(kg) |
| Volume | 9.59(cubic meter) |
| Rated Load | 9140(Kg) |
| Curb Weight | 6660(kg) |
| Dimensions | 8200,7700×2500×3200(mm) |
| Approaching/Departuring Angle | 17/12,17/11(°) |
| Front/Rear Overhang | 1230/2470,1230/2520(mm) |
| Number of Axles | 2 |
| Wheelbase | 3950,4500,4700,3400,3700,5200,5600(mm) |
| Axle Load | 5600/10400(kg) |
| Max Speed | 90 (km/h) |
| Chassis type | EQ1165LJ9BDE-F3 |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/10+7,8/- |
| Tire | 9.00R20,10.00R20 |
| Front Wheel Track | 1858,1949,1765,1891(mm) |
| Rear Wheel Track | 1806,1865,1750(mm) |
| Chassis Discharge Standard | GB17691-2005 National V Emission Standards, GB3847-2005 |
| Fuel Type | Diesel |
| Engine Model | YC4EG170-50, YC4EG185-50, ISB180 50, ISD160 50, ISB210 50, YCD4P4S-170, YCD4P4S-140, YC4S160-50, YC4D150-50 |
| Engine Displacement | 3767 - 5900(ml) |
| Engine Max Power | 105 - 155(kw) |
