| Basic Information | |||
| Usage | Tree Sprinkling Tanker | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 National VI Emission Standards | ||
| Length | 7230mm | ||
| Width | 2250mm | ||
| Height | 2700,2850mm | ||
| Curb Weight | 4720kg | ||
| Gross Weight | 11995kg | ||
| Max Speed | 103km/h | ||
| Chassis | |||
| Chassis Model | EQ1125SJ8CDC | ||
| Front/Rear Overhang | 1130/2300mm | ||
| Number of Leaf Springs | 8/10+7,12/12+9 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3800,3950,4050,4100,4400,3600mm | ||
| Axle Load | 4350/7645kg | ||
| Front Wheel Track | 1745,1802,1820,1842,1765mm | ||
| Rear Wheel Track | 1630,1650,1800,1720mm | ||
| Approaching/Departuring Angle | 20/13° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 245/70R19.5,8.25R20,245/70R19.5 16PR,8.25R20 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D4.0NS6B170 | 96 - 162 kW | 2499 - 4461ml | |
| D4.0NS6B185 | |||
| YCS04190-68 | |||
| ZD30D16-6N | |||
| D25TCIF1 | |||
| D30TCIF1 | |||
| D40TCIF1 | |||
| D45TCIF1 | |||
| NV30-C6G | |||
| NV30-C6C | |||
| NV30-C6D | |||
| CY4SK161 | |||
| CY4SK261 | |||
| CY4SK361 | |||
| YCY30165-60 | |||
| D4.0NS6B160 | |||
| CY4BK261 | |||
| YCY24140-60 | |||
| Q28-130E60 | |||
| H30-165E60 | |||
| D4.0NS6B195 | |||
| CA4DD2-18E6-30 | |||
