| Model | CLW5250GPSD6 |
| Gross Weight | 25000(kg) |
| Volume | 14.82(cubic meter) |
| Rated Load | 14120,14185(Kg) |
| Curb Weight | 10685(kg) |
| Dimensions | 10260×2550×3200(mm) |
| Approaching/Departuring Angle | 20/13(°) |
| Front/Rear Overhang | 1440/3120(mm) |
| Number of Axles | 3 |
| Wheelbase | 4350+1350,4750+1350,5400+1350,5700+1350,5900+1350,3600+1350(mm) |
| Axle Load | 7000/18000 (kg) (two axles) |
| Max Speed | 89(km/h) |
| Chassis type | DFV1253GP6DJ |
| Number of Tires | 10 |
| Number of Leaf Spring | 9/10,8/13,9/13 |
| Tire | 11.00-20 16PR,11.00R20 18PR,12R22.5 18PR,295/80R22.5 18PR |
| Front Wheel Track | 1940,1965,1980,2020 (mm) |
| Rear Wheel Track | 1860/1860(mm) |
| Chassis Discharge Standard | GB17691-2018 National Ⅵ Emission Standards |
| Fuel Type | Diesel |
| Engine Model | D6.7NS6B320, D6.7NS6B260, D6.7NS6B230, B6.2NS6B260, B6.2NS6B230, YCS06270-60, YCS06245-60, YCS06245-60A, YCK08300-60 |
| Engine Displacement | 6200 - 7698(ml) |
| Engine Max Power | 169 - 231(kw) |
