| Model | CLW5184GSSD6 |
| Gross Weight | 18000(kg) |
| Volume | 10.77(cubic meter) |
| Rated Load | 10260,10325(Kg) |
| Curb Weight | 7545(kg) |
| Dimensions | 8580,8550,8380,8350×2550×3200(mm) |
| Approaching/Departuring Angle | 15/12(°) |
| Front/Rear Overhang | 1430/2450,1400/2450 (mm) |
| Number of Axles | 2 |
| Wheelbase | 3800,3950,4200,4500,4700,5000,5300,5800(mm) |
| Axle Load | 6500/11500(kg) |
| Max Speed | 89(km/h) |
| Chassis type | DFH1180EX8 |
| Number of Tires | 6 |
| Number of Leaf Spring | 7/9+6,8/10+8,8/9+6 |
| Tire | 10.00R20 18PR,275/80R22.5 18PR |
| Front Wheel Track | 1876,1896,1920,1950 (mm) |
| Rear Wheel Track | 1820,1860(mm) |
| Chassis Discharge Standard | GB3847-2005,GB17691-2018 National Ⅵ Emission Standards |
| Fuel Type | Diesel |
| Engine Model | DDi50E190-60, D4.5NS6B190, D6.7NS6B230, B6.2NS6B210, B6.2NS6B230 |
| Engine Displacement | 4500 - 6700(ml) |
| Engine Max Power | 140 - 169(kw) |
