| Model | CLW5160GPSZD6 |
| Gross Weight | 16000(kg) |
| Volume | 9.66(cubic meter) |
| Rated Load | 9205,9270(Kg) |
| Curb Weight | 6600(kg) |
| Dimensions | 8390,7840,8250,8150,7700,7600×2550×3250(mm) |
| Approaching/Departuring Angle | 18/13(°) |
| Front/Rear Overhang | 1440/2450,1300/2450,1200/2450(mm) |
| Number of Axles | 2 |
| Wheelbase | 3800,3950,4200,4500,4700,5100(mm) |
| Axle Load | 5600/10400(kg) |
| Max Speed | 89(km/h) |
| Chassis type | DFV1163GP6DJ |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/10+8,3/4+3,3/10+8,8/10+7 |
| Tire | 9.00R20 16PR,10.00R20 16PR,10.00R20 18PR,275/80R22.5 18PR |
| Front Wheel Track | 1810,1880,1920,1940,1965(mm) |
| Rear Wheel Track | 1800,1820,1860(mm) |
| Chassis Discharge Standard | GB17691-2018 National Ⅵ Emission Standards |
| Fuel Type | Diesel |
| Engine Model | YCS04200-68, D4.0NS6B195, D4.0NS6B170, D30TCIF1, D25TCIF1, YCS04180-68, YCY30165-60 |
| Engine Displacement | 2,499 – 4,156(ml) |
| Engine Max Power | 110 -147(kw) |
