Low fuel consumption, long life! Dongfeng pure electric kitchen garbage truck

The food waste truck is a sanitation product used for collecting and transporting food waste in the catering service industry (hotels, restaurants, institutions, school canteens, etc.).

EQ5120TCASBEV pure electric kitchen garbage truck is a vehicle with beautiful appearance, generous and simple. It is modified from Dongfeng's second-class chassis with special working devices such as carriage, dozer, flip mechanism, hydraulic system and electrical system. It is equipped with Dongfeng Chaochai or Anhui Quanchai engine, and its emissions meet the National VI standard. It adopts a highly intelligent control system integrating electricity and hydraulics. The main control chip adopts the control module of Siemens of Germany. The performance is stable and reliable, and the operation is simple and convenient (optional wire controller). The volume of the carriage is leading in the industry, with a total volume of 10-11m³ and an effective volume of 8-9m³. The joint between the tail of the carriage and the rear door adopts a specially developed special reinforced sealing strip. The two top cylinders control the opening and closing, and the two bottom cylinders control the locking of the wedge structure.
The top design has an adjustable lock, high structural strength, and is easy to open. It adopts electromechanical and hydraulic integrated control, and there is no leakage during use and vehicle driving. The sealing effect is very good, and secondary pollution is eliminated. The engine speed changes automatically with the working state, the idle speed is ≤800 rpm, and the working (bushing, high-pressure cleaning) speed is ≤1500 rpm; when unloading (high-pressure cleaning), the fuel consumption is low and the operating cost is low. The main body of the car, the rear door, the bulldozer and other key parts are made of stainless steel plates, which are resistant to acid and alkali corrosion and have a long service life.


This product has a wide range of applications and low requirements for environmental conditions. It can be used in urban streets, residential areas, catering industry, hotels and canteens, etc. It is mainly used for the collection and transportation of domestic waste.
The garbage is poured into the car through the flip mechanism from the side of the vehicle, and the initial separation of oil and water in the kitchen waste is achieved. It has multiple functions such as garbage collection, garbage compression, garbage transportation, and garbage unloading.The vehicle side flip mechanism can match 120L and 240L standard plastic trash cans at the same time, which is suitable for the collection and transportation of various kitchen waste.
