Big hopper, big capacity! Fulongma solves the problem of waste transfer

The ZTXA45 series mobile garbage compressor is suitable for front-end unloading of small and medium-sized garbage collection vehicles, meeting the unloading needs of compressed garbage trucks with a total mass of 8 tons. The maximum box volume can reach 22m³, which solves the problem of long transportation distances from small and medium-sized garbage collection vehicles to the terminal, low single transfer volume, poor operating economics and other garbage transfer problems.

Adopting a conjoined large hopper structure with a lifting force of more than 2t. The internal depth of the hopper is 3m, the internal width is 2.34m, and the volume is 4.5m³. It can realize complete discharge of small and medium-sized garbage collection trucks at one time and avoid congestion of incoming trucks caused by multiple discharges. And problems such as secondary pollution of unloading materials.

The volume of the compression bin is greater than 6m³, and the single compression volume is greater than 1.7m³. It adopts a double-pump system, the compression cycle time is less than 35s, and the hopper and push plate can be linked to move at the same time. The operation efficiency is high. The maximum compression force of the pusher head reaches 400kN, and the garbage compression density is high and large single transport volume.

Both the front maintenance door and the rear door adopt adjustable locking mechanisms and labyrinth sealing strips, which have good sealing effects and avoid secondary pollution problems such as dripping, spilling, and leakage during operation.

The power chamber and operating box are placed behind the operating range of the loading mechanism. The loading mechanism has automatic buffering and explosion-proof pipe safety devices, and multiple interlocks between each action. The equipment operation is safe, low-noise, and the system operation is stable, reliable and intelligent.

The equipment is small in size, flexible and can be transferred immediately after collection. It can meet the collection and transfer needs of domestic waste in urban and rural streets, commercial areas, residential areas, factories, schools, hospitals and other places.
