A well-known Chinese manufacturer’s self-priming centrifugal pump is used, and the chassis engine powers the water pump. It uses the low-level flushing work mode that was invented domestically.
To water trees at different heights and positions along the road, one can use the rear water gun, which is placed at the right-rear part of the truck and is flexible to operate. The operation is more safely conducted when the operator and driver can simultaneously communicate with gestures or language. The back water gun may be modified into a column or mist, and the high spray gun also offers an additional fire-fighting capability.
The front left and right sprinklers, as well as the back left and right column side flushing devices, allow for left and right, up and down adjustment of the nozzles.
The rear bumper has two nozzles that are used for daily misting to boost humidity and lower dust.
To make it easier for the operators to water the flower gardens or green belts on both sides of the road, a 20-meter low-pressure hose winch is fitted on the left side of the rear platform.
In the cab, the sprinkler control feature is accessible.
Corrosion-resistant materials are used to construct the sprinkler system pipes and switch control valves. The interior of the water storage tank, which is composed of the Q235B material, has undergone a specific procedure to stop corrosion. (A stainless steel tank is available.)
A low water level sensor alarm system is installed in the water tank, and it can sound an automatic alarm when the water level is low.
